H71905C-AC-P4-2RZ
Precision Bearings > H719 - 2RZC/P4 Double - Sealed Angular Contact Ball Bearing
H71905C-AC-P4-2RZ - Precision Bearings - H719 - 2RZC/P4 Double - Sealed Angular Contact Ball Bearing
| Parameter | α=15°(C) | α=25°(AC) |
|---|---|---|
| Model | H71905C-AC-P4-2RZ | H71905C-AC-P4-2RZ |
| d (mm) | 25 | 25 |
| D (mm) | 42 | 42 |
| B (mm) | 9 | 9 |
| Load Rating Cr (kN) | 7.6 | 7.2 |
| Load Rating C0r (kN) | 6.5 | 6.2 |
| Limiting Speed Grease (r/min) | 33000 | 29000 |
| Limiting Speed Oil (r/min) | 49000 | 44000 |
| Cage | Bakelite | Bakelite |
Product Details
The H71905C – AC – P4 – 2RZ is part of the H719 – 2RZC/P4 Double – Sealed Angular Contact Ball Bearing series within our Precision Bearings range. It is engineered for high-performance industrial use and delivers reliable operation under demanding working conditions.
Typical applications include: industrial machinery and OEM applications. For detailed dimensions and load ratings, please refer to the specification table above. Contact FIJ for bulk pricing, technical support or customized solutions.
Request a Quote for this Product
